Yanmar 4JH80 Marine Diesel Engine 80hp
$15,196.00
- Description
Description
Yanmar 4JH80 Marine Diesel Engine 80HP
The Yanmar 4JH80 marine diesel engine delivers a maximum 58.8 kW / 80 MHP at 3,200 rpm, combining Bosch common rail injection with turbocharged, intercooled performance. Its four-cylinder design provides an electronically managed inboard propulsion option for sailboats and small craft. YANMAR Marine International
Looking for a Yanmar 4JH80 for sale? Request engine pricing, marine gearbox options and delivery costs from MSS Motorsports UG. Specify whether you need an engine for an existing drivetrain or a complete propulsion package.
Common Rail Power for Cruising and Repowering
Part of the Yanmar JH-CR Series, the 4JH80 brings modern fuel management to marine auxiliary propulsion. Yanmar developed the range around its TNV engine-block platform with a custom Bosch common rail system.
For owners planning a replacement or new installation, key features include:
- Precise fuel delivery: Electronic management uses sensor feedback to control injection timing and fuel quantity.
- Cruising comfort: Yanmar emphasizes smooth operation and low noise across the JH-CR range.
- Turbocharged output: Turbocharging and intercooling support the 4JH80’s rated performance.
- Drivetrain choice: Documented configurations include shaft-drive marine gears and saildrives. www.yanmar.com
Actual cruising speed, fuel consumption and onboard noise depend on hull design, loading, propeller selection and installation quality.
Technical Specifications
| Specification | Manufacturer Reference |
|---|---|
| Engine model | Yanmar 4JH80 |
| Engine configuration | Four-cylinder inline, four-stroke diesel |
| Maximum crankshaft output | 58.8 kW / 80 MHP at 3,200 rpm |
| Displacement | 1.995 litres, commonly rounded to 2.0 litres |
| Bore × stroke | 84 × 90 mm |
| Fuel injection | Direct injection with Bosch common rail |
| Engine management | Electronic |
| Aspiration | Turbocharged and intercooled |
| Cooling | Freshwater coolant circuit with seawater-cooled heat exchanger |
| Electric starter | 12V, 1.4 kW |
| Alternator reference | 12V, 125A |
| Dry engine weight | 229 kg, without gearbox |
| Reference dimensions | 909 × 613 × 675 mm, including KM4A2 marine gear |
MHP means metric horsepower. Reference dimensions vary with the gearbox, drive and exhaust elbow. Use the drawing for your proposed configuration when checking engine beds, access and installation space. yanmar.com
Review the official Yanmar 4JH80 specifications for manufacturer information.
Marine Gearbox Options for Shaft Drive
Yanmar documentation identifies several transmission configurations:
- KM4A2: Down-angle marine gear with a mechanical cone clutch.
- KMH4A: Down-angle marine gear with a hydraulic multi-disc clutch.
- ZF25A: Hydraulic multi-disc transmission.
- ZF30M: Mechanical multi-disc transmission. yanmar.com
Choose the gearbox and reduction ratio around vessel resistance, propeller demand, shaft arrangement and intended use. Include your existing gearbox model and ratio when enquiring about an engine replacement.
SD60 and SD110 Saildrive Configurations
The Yanmar 4JH80 has documented pairings with two distinct saildrive systems:
SD60 saildrive: Uses a mechanical multi-disc clutch and is listed by Yanmar as a compatible drive for the 4JH80. YANMAR Marine International
SD110 saildrive: Uses hydraulically actuated multi-disc clutches with electric shift control. Yanmar specifically offers this system with the 4JH80 and 4JH110. YANMAR Marine International
For a saildrive project, confirm the exact drive version, hull interface, mounting arrangement, controls and propeller requirements. Assess the complete installation before selecting a replacement or conversion package.
Helm Controls and Engine Monitoring
Yanmar’s reference package lists a B25 instrument panel, mechanical throttle sensor, flexible mounts and a fuel pre-filter with water separator. Current product information also identifies optional VC20/VC30 vessel controls and NMEA 2000 engine monitoring. YANMAR Marine International
The engine retains electronic fuel management when operated through a mechanical helm control. Specify the required panel, control stations and harness lengths, and confirm the supplied equipment in the quotation.
Match the Rating to Your Operating Requirements
Yanmar’s recreational-use operating manual lists a continuous reference output of 53.5 kW / 72.8 MHP at 3,101 rpm. The advertised 80 MHP is maximum crankshaft output. yanmar.com
Select power against your vessel’s cruising requirements and follow the applicable operating guidance. Commercial enquiries should include expected annual hours and load profile for assessment.
For a higher-output model in the same range, compare the Yanmar 4JH110 marine diesel engine.
Pricing, Package Contents and Warranty
Request an itemised quotation confirming:
- Engine condition, identification and available documentation.
- Gearbox or saildrive, controls and included installation accessories.
- Availability, lead time, delivery costs and applicable warranty terms.
Obtain written warranty details, including eligibility, registration requirements, exclusions and the claims process. Agree installation and commissioning responsibilities before ordering.
Frequently Asked Questions
Does the Yanmar 4JH80 use common rail injection?
Yes. It uses Bosch common rail direct injection with electronic engine management.
Does the 229 kg engine weight include a gearbox?
No. The published figure excludes marine gear. Add the selected transmission or drive and other equipment when assessing the installation. yanmar.com
Can it replace an older Yanmar marine engine?
It may suit a repower, subject to checking engine mounts, drivetrain alignment, cooling, exhaust, fuel supply and electrical systems.
Request Your Yanmar 4JH80 Quote
Contact MSS Motorsports UG for a Yanmar 4JH80 quotation. Include your vessel model, current engine, gearbox or drive model and ratio, preferred controls, intended use, purchase timing, and billing and delivery addresses.
